Chaos Engineering For Prometheus

Introduction

Gremlin is a simple, safe and secure service for performing Chaos Engineering experiments through a SaaS-based platform. Prometheus is an open-source systems monitoring and alerting toolkit originally built at SoundCloud. Prometheus is now a standalone open source project and maintained independently of any company. Prometheus joined the Cloud Native Computing Foundation in 2016 as the second hosted project, after Kubernetes. Datadog is a monitoring service for cloud-scale applications, providing monitoring of servers, databases, tools, and services, through a SaaS-based data analytics platform.

This tutorial shows:

  • How to install Docker
  • How to install Prometheus for monitoring and alerting
  • How to install Gremlin in a Docker container for Chaos Engineering experiments
  • How to install Datadog in a container to monitor Prometheus
  • How to create a Shutdown attack from a Gremlin Container against a Prometheus Container
  • How to ensure your Docker containers automatically restart when they are killed
  • Additional Chaos Engineering experiments to run on Prometheus

Chaos Engineering Hypothesis

Prometheus’ storage model groups ingested samples into blocks of two hours. Each two hour block containers one or more chunk files that contain all time series samples for that window of time. The block for currently incoming samples is kept in memory and not fully persisted. It is secured against crashed by a WAL (write-ahead-log) that can be replayed when the prometheus server restarts after a crash. The limitation of local storage is that it is not clustered or replicated. Thus, it is not scalable or durable in the face or disk or node outages. There is a open source project called Thanos which aims to be a highly available Prometheus setup with long term storage capabilities. For the purposes of this tutorial we will run Chaos Engineering experiments on the Prometheus server running inside a Docker container. The Chaos Engineering experiment we will perform is a shutdown of the Prometheus Docker container.

prom architecture

Image source: Prometheus Overview

Prerequisites

Step 1 - Installing Docker

In this step, you’ll install Docker.

Add Docker’s official GPG key:

curl -fsSL https://download.docker.com/linux/ubuntu/gpg | sudo apt-key add -

Use the following command to set up the stable repository.

sudo add-apt-repository "deb [arch=amd64] https://download.docker.com/linux/ubuntu $(lsb_release -cs) stable"

Update the apt package index:

sudo apt-get update

Make sure you are about to install from the Docker repo instead of the default Ubuntu 16.04 repo:

apt-cache policy docker-ce

Install the latest version of Docker CE:

sudo apt-get install docker-ce

Docker should now be installed, the daemon started, and the process enabled to start on boot. Check that it is running:

sudo systemctl status docker

Type q to return to the prompt.

Make sure you are in the Docker usergroup, replace tammy with your username:

sudo usermod -aG docker tammy

Next we will create an Prometheus container and monitor the new container directly by joining the container’s pid namespace.

Step 2 - Installing Prometheus with Docker

Prometheus is an open-source systems monitoring and alerting toolkit.

First we'll create a directory in /etc for Prometheus' configuration files and a directory in /var/lib for its data.

sudo mkdir /etc/prometheus
sudo mkdir /var/lib/prometheus

First create a Prometheus configuration file on the host filesystem:

vim /etc/prometheus/prometheus.yml

Add the following contents to the yml file, replace the IP address in red with your own IP address:

# A scrape configuration scraping a Node Exporter and the Prometheus server# itself.scrape_configs:  # Scrape Prometheus itself every 5 seconds.  - job_name: 'prometheus'    scrape_interval: 5s    target_groups:      - targets: ['localhost:9090']  # Scrape the Node Exporter every 5 seconds.  - job_name: 'node'    scrape_interval: 5s    target_groups:  - targets: ['68.183.116.87:9100']

Start the Prometheus Docker container with your configuration file:

docker run -d -p 9090:9090 prom/prometheus

List all running Docker containers using the following command:

docker ps

To start the Node Exporter on port 9100 using Docker:

docker run -d -p 9100:9100 -v "/proc:/host/proc" -v "/sys:/host/sys" -v "/:/rootfs" --net="host" prom/node-exporter

Now you will be able to view your Prometheus metrics.

The Prometheus server should now automatically start scraping the Node Exporter.

Step 3 - View your Prometheus metrics

You can also verify that Prometheus is serving metrics about itself by navigating to its metrics endpoint, e.g. http://68.183.116.87:9090/metrics, replacing the IP Address with your own.

To graph expressions, navigate to http://68.183.116.87:9090/graph and use the "Graph" tab, replacing the IP Address with your own.

For example, enter the following expression to graph the per-second rate of chunks being created in the self-scraped Prometheus:

rate(prometheus_tsdb_head_chunks_created_total[1m])

You will a graph similar to below:

prom view metrics

Experiment with the graph range parameters and other settings.

Step 4 – Set up your Gremlin client credentials

After you have created your Gremlin account (sign up here) you will need to find your Gremlin Daemon credentials. Login to the Gremlin App using your Company name and sign-on credentials. These were emailed to you when you signed up to start using Gremlin.

Navigate to Team Settings and click on your Team. Click the blue Download button to save your certificates to your local computer. The downloaded certificate.zip contains both a public-key certificate and a matching private key.

Gremlin certificates

Unzip the downloaded certificate.zip on your laptop and copy the files to the server you will be using with a Linux file transfer tool such as rsync, sftp or scp. Alternatively, you can store these certificates in a storage service such as AWS S3. For example:

rsync -avz /Users/tammybutow/Desktop/tammy-client.pub_cert.pem tammy@68.183.116.87:/var/lib/
rsync -avz /Users/tammybutow/Desktop/tammy-client.priv_key.pem tammy@68.183.116.87:/var/lib/

Store your Gremlin client credentials as environment variables, for example:

export GREMLIN_TEAM_ID=3f242793-018a-5ad5-9211-fb958f8dc084
export GREMLIN_TEAM_CERTIFICATE_OR_FILE="$(cat /var/lib/tammy-client.pub_cert.pem)"
export GREMLIN_TEAM_PRIVATE_KEY_OR_FILE="$(cat /var/lib/tammy-client.priv_key.pem)"

Run the Gremlin Daemon in a Container

Use docker run to pull the official Gremlin Docker image and run the Gremlin daemon:

$ sudo docker run -d \    --net=host \    --pid=host \    --cap-add=NET_ADMIN \    --cap-add=SYS_BOOT \    --cap-add=SYS_TIME \    --cap-add=KILL \    -e GREMLIN_TEAM_ID="${GREMLIN_TEAM_ID}" \    -e GREMLIN_TEAM_CERTIFICATE_OR_FILE="${GREMLIN_TEAM_CERTIFICATE_OR_FILE}" \    -e GREMLIN_TEAM_PRIVATE_KEY_OR_FILE="${GREMLIN_TEAM_PRIVATE_KEY_OR_FILE}" \    -v /var/run/docker.sock:/var/run/docker.sock \    -v /var/log/gremlin:/var/log/gremlin \    -v /var/lib/gremlin:/var/lib/gremlin \    gremlin/gremlin daemon

Use docker ps to see all running Docker containers:

sudo docker ps
CONTAINER ID        IMAGE                COMMAND                  CREATED             STATUS              PORTS                    NAMES
b281e749ac33        gremlin/gremlin      "/entrypoint.sh daem…"   5 seconds ago       Up 4 seconds                                 relaxed_heisenberg
5b793e7e97bf        prom/node-exporter   "/bin/node_exporter"     16 minutes ago      Up 16 minutes                                condescending_heisenberg
2bb6286816d3        prom/prometheus      "/bin/prometheus --c…"   17 minutes ago      Up 17 minutes       0.0.0.0:9090->9090/tcp   infallible_haibt

Jump into your Gremlin container with an interactive shell (replace b281e749ac33 with the real ID of your Gremlin container):

docker exec -it b281e749ac33 /bin/bash

From within the container, check out the available attack types:

gremlin help attack-container
Usage: gremlin attack-container CONTAINER TYPE [type-specific-options]Type "gremlin help attack-container TYPE" for more details:  blackhole # An attack which drops all matching network traffic  cpu   # An attack which consumes CPU resources  io    # An attack which consumes IO resources  latency # An attack which adds latency to all matching network traffic  memory  # An attack which consumes memory  packet_loss # An attack which introduces packet loss to all matching network traffic  shutdown  # An attack which forces the target to shutdown  dns   # An attack which blocks access to DNS servers  time_travel # An attack which changes the system time.  disk    # An attack which consumes disk resources  process_killer  # An attack which kills the specified process

Then exit the container.

Step 5 – Installing the Datadog agent in a Docker container

To install Datadog in a Docker container you can use the Datadog Docker easy one-step install.

Run the following command, replacing the item in red with your own API key:

$ docker run -d --name dd-agent -v /var/run/docker.sock:/var/run/docker.sock:ro -v /proc/:/host/proc/:ro -v /sys/fs/cgroup/:/host/sys/fs/cgroup:ro -e DD_API_KEY=7cfe87ac24e0ce166be9c96aea1f3f88 datadog/agent:latest

It will take a few minutes for Datadog to spin up the Datadog container, collect metrics on your existing containers and display them in the Datadog App.

View your Docker Containers in Datadog, you should see the following on the host Dashboard:

Datadog Prometheus

Step 6 – Run a Shutdown Attack against the Prometheus container from a Gremlin container

We will use the Gremlin CLI attack command to create a CPU attack.

Now use the Gremlin CLI (gremlin) to run a CPU attack from within a Gremlin container:

sudo docker run -i \    --net=host \    --pid=host \    --cap-add=NET_ADMIN \    --cap-add=SYS_BOOT \    --cap-add=SYS_TIME \    --cap-add=KILL \    -e GREMLIN_TEAM_ID="${GREMLIN_TEAM_ID}" \    -e GREMLIN_TEAM_CERTIFICATE_OR_FILE="${GREMLIN_TEAM_CERTIFICATE_OR_FILE}" \    -e GREMLIN_TEAM_PRIVATE_KEY_OR_FILE="${GREMLIN_TEAM_PRIVATE_KEY_OR_FILE}" \    -v /var/run/docker.sock:/var/run/docker.sock \    -v /var/log/gremlin:/var/log/gremlin \    -v /var/lib/gremlin:/var/lib/gremlin \    gremlin/gremlin attack-container 2bb6286816d3 shutdown

This attack will shutdown the Prometheus container and it will not be automatically recreated.

Use docker ps to confirm that the Prometheus container is no longer running:

docker ps
CONTAINER ID        IMAGE                  COMMAND                  CREATED              STATUS                       PORTS                    NAMES
d2c266591df4        datadog/agent:latest   "/init"                  About an hour ago    Up About an hour (healthy)   8125/udp, 8126/tcp       dd-agent
b281e749ac33        gremlin/gremlin        "/entrypoint.sh daem…"   About an hour ago    Up About an hour                                      relaxed_heisenberg
5b793e7e97bf        prom/node-exporter     "/bin/node_exporter"     About an hour ago    Up About an hour                                      condescending_heisenberg
e030fc006904        nginx                  "nginx -g 'daemon of…"   About an hour ago    Up About an hour             80/tcp                   relaxed_hamilton

Step 7 – How to ensure your containers automatically restart when they are killed

To create Docker containers that restart automatically you will need to you docker’s restart functionality. Start Prometheus again using the following Docker command, this includes --restart unless-stopped which will ensure your Prometheus Docker container is restarted.

docker run -d -p 9090:9090 --restart unless-stopped prom/prometheus

Use docker ps to confirm that the Prometheus container is now running again:

docker ps
CONTAINER ID        IMAGE                  COMMAND                  CREATED              STATUS                       PORTS                    NAMES
3ce13dadb8ed        prom/prometheus        "/bin/prometheus --c…"   About a minute ago   Up 8 seconds                 0.0.0.0:9090->9090/tcp   keen_babbage
d2c266591df4        datadog/agent:latest   "/init"                  About an hour ago    Up About an hour (healthy)   8125/udp, 8126/tcp       dd-agent
b281e749ac33        gremlin/gremlin        "/entrypoint.sh daem…"   About an hour ago    Up About an hour                                      relaxed_heisenberg
5b793e7e97bf        prom/node-exporter     "/bin/node_exporter"     About an hour ago    Up About an hour                                      condescending_heisenberg
e030fc006904        nginx                  "nginx -g 'daemon of…"   About an hour ago    Up About an hour             80/tcp                   relaxed_hamilton

The average lifespan of a container is 2.5 days, visit the Docker guide on starting containers automatically to learn more. You should not be getting paged for containers or hosts being down. You should be handling this in an automated manner.

Step 8 – Additional Chaos Engineering experiments to run on Prometheus

There are many Chaos Engineering experiments you could possibly run on your Prometheus infrastructure:

  • Time Travel Gremlin - will changing the clock time of the host impact how Prometheus processes metrics?
  • Latency & Packet Loss Gremlins - will they impact the ability to serve the UI?
  • Disk Gremlin - will filling up the disk crash the Prometheus host? Will the WAL the perform as expected?

We encourage you to run these Chaos Engineering experiments and share your findings! You can get access to Gremlin.

Conclusion

This tutorial has explored how to install Prometheus and Gremlin in Docker containers for your Chaos Engineering experiments. We then ran a shutdown Chaos Engineering experiment on the Prometheus container using the Gremlin Shutdown attack.
