Automating a Chaos Engineering Environment on AWS with Terraform

Ho Ming Li
Manager, Solution Architecture
Last Updated:
April 24, 2018
Categories:
Chaos Engineering
,

Chaos as Code (CaC) enables you to simply, safely and securely run, schedule and manage Chaos Engineering experiments. This tutorial will demonstrate how to use Hashicorp Terraform to automate your Chaos Engineering experiments.

Hashicorp’s Terraform is an open source tool that enables you to define infrastructure as code, increasing productivity and transparency. Terraform codifies APIs into declarative configuration files that can be shared amongst team members, treated as code, edited, reviewed, and versioned.

In this tutorial, we will demonstrate how to use Terraform to create an EC2 instance and setup Gremlin to perform Chaos Engineering experiments. You will then perform a Chaos Engineering experiment on your EC2 instance in the form of a Gremlin Latency Attack. This tutorial will help you get started with using Terraform, and give you an idea of how it can be used for Chaos as Code (CaC).

Prerequisites

  • AWS Account (see EC2 permissions in Appendix A)
  • Gremlin Account (with Team ID and Secret ready - sign up here)
  • Terraform (for automating resource creation)
  • AWS CLI (nice to have to interact with your AWS environment)

Step 0: Verify Terraform Installation

If you don’t have Terraform installed, You can download the appropriate package here.On your local machine, verify your Terraform installation. You should see output like this:

BASH

terraform
Usage: terraform [--version] [--help]  [args]

The available commands for execution are listed below.
The most common, useful commands are shown first, followed by
less common or more advanced commands. If you're just getting
started with Terraform, stick with the common commands. For the
other commands, please read the help and docs before usage.

Common commands:
    apply              Builds or changes infrastructure
    console            Interactive console for Terraform interpolations
<...>

All other commands:
    debug              Debug output management (experimental)
    force-unlock       Manually unlock the terraform state
    state              Advanced state management

Step 1: Create the VPC Environment

For separation, create two directories, one for VPC specification and another for Instance specification.

On your local machine:

BASH

mkdir -p ~/terraform/vpc ~/terraform/instance
cd ~/terraform/vpc

Inside the vpc directory, create the following <span class="code-class-custom">vpc.tf</span> file using a text editor. We'll use vim throughout this tutorial. Replace the example region/az, tags, IP space and security group as required to set these up correctly for your AWS VPC.

BASH

vim vpc.tf

Enter the following information, changing the <span class="code-class-custom">region</span>, <span class="code-class-custom">name</span>, <span class="code-class-custom">cidr</span>, <span class="code-class-custom">azs</span>, <span class="code-class-custom">public_subnets</span>, <span class="code-class-custom">owner</span>, <span class="code-class-custom">environment</span>, <span class="code-class-custom">name</span>, and <span class="code-class-custom">description</span> fields with your own data.

BASH

provider "aws" {
  region = "us-west-2"
}

module "vpc" {
  source = "terraform-aws-modules/vpc/aws"
  name = "gremlin_vpc"

  cidr = "10.10.0.0/16"

  azs               = ["us-west-2a"]
  public_subnets    = ["10.10.1.0/24"]

  tags = {
    Owner       = "your_name"
    Environment = "chaos"
  }
}

module "security_group" {
  source = "terraform-aws-modules/security-group/aws"
  name      = "ssh"
  description = "ssh from anywhere"
  vpc_id    = "module.vpc.vpc_id"

  ingress_cidr_blocks = ["0.0.0.0/0"]
  ingress_rules     = ["ssh-tcp","all-icmp"]
  egress_rules      = ["all-all"]
}

This <span class="code-class-custom">vpc.tf</span> terraform template file uses the aws provider, defines a VPC with a single public subnet in an availability zone, and a security group within this VPC to allow SSH access.

Let’s run a couple of commands to stand up the underlying networking infrastructure.

On your local machine:

BASH

terraform init
terraform apply

Terraform will compute the resources that needs to be created, and you will then be prompted:

BASH

Do you want to perform these actions?
  Terraform will perform the actions described above.
  Only 'yes' will be accepted to approve.

  Enter a value:

Enter <span class="code-class-custom">yes</span>, and Terraform will go ahead and create the resources. On successful completion you will see the following result:


Apply complete! Resources: 12 added, 0 changed, 0 destroyed.

Note the Security Group ID (sg-xxxxxxxx) and Subnet ID (subnet-xxxxxxxx) for later.

That’s it! With just a few commands you have created a new VPC with internet gateway, a subnet in <span class="code-class-custom">us-west-2a</span>, a route table for the public subnet, and a security group allowing ssh access.

Step 2: Launch an Instance that registers to Gremlin

Now that you have the underlying networking environment prepared, and let’s focus on automating the creation of an instance.

Switch to the instance directory you created in Step 1:

BASH

cd ~/terraform/instance

Create the <span class="code-class-custom">instance.tf</span> template that defines the specification of the instance to launch. It references the <span class="code-class-custom">userdata.sh</span> script to install and authenticate a Gremlin agent at launch. You will create this <span class="code-class-custom">userdata.sh</span> file at a later step.

To populate the <span class="code-class-custom">instance.tf</span> template, you will need the following

If you do not recall the Security Group ID and/or the Subnet ID from the earlier step, you can retrieve them via the aws cli.

BASH

aws ec2 describe-security-groups --filters Name=group-name,Values=ssh --query 'SecurityGroups[0].GroupId' --output text

This is an example of the result you will see:

BASH

sg-91155cee

aws ec2 describe-subnets --filters Name=tag:Name,Values="gremlin_vpc*" --query 'Subnets[0].SubnetId' --output text


This is an example of the result you will see: <span class="code-class-custom">subnet-cbbd68b2</span>

Populate <span class="code-class-custom">instance.tf</span> template file with the following content. Modify <span class="code-class-custom">your_name</span>,<span class="code-class-custom"> subnet_id</span>, <span class="code-class-custom">vpc_security_group_ids</span>, and <span class="code-class-custom">key_name</span> accordingly.

On your local machine in the /terraform/instance directory, create the <span class="code-class-custom">instance.tf</span> file:

BASH

vim instance.tf

Note: If you are new to vim or need a refresher for vim commands, refer to this vim cheatsheet.Enter the following information, modifying <span class="code-class-custom">region</span>, <span class="code-class-custom">name</span>, <span class="code-class-custom">subnet_id</span>, <span class="code-class-custom">key_name</span>, and <span class="code-class-custom">Owner</span> accordingly:

BASH

provider "aws" {
  region = "us-west-2"
}

data "aws_ami" "amazon_linux" {
  most_recent = true
  owners = ["amazon"]

  filter {
    name = "name"
    values = [ "amzn-ami-hvm-*-x86_64-gp2", ]
  }
}

module "ec2" {
  source = "terraform-aws-modules/ec2-instance/aws"
  instance_count = 1

  name                      = "gremlin-instance"
  ami                       = "${data.aws_ami.amazon_linux.id}"
  associate_public_ip_address = true
  instance_type             = "t2.micro"
  subnet_id                 = "subnet-cbbd68b2"
  vpc_security_group_ids    = ["sg-91155cee"]
  key_name                  = "changeme"
  user_data                 = "${file("userdata.sh")}"

  tags {
    Owner       = "your_name"
    Environment = "chaos"
    DeployFrom = "terraform"
  }
}

This instance template file defines a t2.micro EC2 instance from the latest Amazon Linux AMI, to be launched in the specified subnet, with the SSH security group created earlier.

Downloading your Gremlin agent certificates

After you have created your Gremlin account (sign up here) you will need to find your Gremlin agent credentials. Login to the Gremlin App using your Company name and sign-on credentials. These were emailed to you when you signed up to start using Gremlin.

Next, navigate to the Team Settings page by clicking the user icon in the top-right corner of the screen (next to the Halt button) and selecting Team Settings. Click on the Configuration tab, then click the blue Download button to save your certificates to your local computer. The downloaded certificate.zip contains both a public-key certificate and a matching private key.

Unzip the downloaded certificate.zip on your laptop. Next, we will create the <span class="code-class-custom">userdata.sh</span> script.

Note
We do not recommend hardcoding your secret in user data for long term use. This article uses this approach for simplicity. While it is possible to base64 encode the user data to obfuscate the plaintext secret, it still is not very secure as it is straightforward to decode.

On your local machine in the /terraform/instance directory, create the <span class="code-class-custom">userdata.sh</span> file:

BASH

vim userdata.sh

Enter the following information, replacing <span class="code-class-custom">GREMLIN_TEAM_ID</span> with your Gremlin team ID, <span class="code-class-custom">GREMLIN_CERTIFICATE</span> with the contents of your public certificate (your <span class="code-class-custom">pub_cert.pem</span> file), <span class="code-class-custom">GREMLIN_PRIVATE_KEY</span> with the contents of your private key (your <span class="code-class-custom">priv_key.pem</span> file), and <span class="code-class-custom">YOUR_NAME</span> with your name:

BASH

#!/bin/bash
yum update -y
curl https://rpm.gremlin.com/gremlin.repo -o /etc/yum.repos.d/gremlin.repo
yum install -y gremlin gremlind
export INSTANCE_ID=$(curl -s http://169.254.169.254/latest/meta-data/instance-id)
echo 'GREMLIN_CERTIFICATE' >> /var/lib/gremlin/pub_cert.pem
echo 'GREMLIN_PRIVATE_KEY' >> /var/lib/gremlin/priv_key.pem
sed -i '/#team_id/c\team_id: GREMLIN_TEAM_ID' /etc/gremlin/config.yaml
sed -i '/#team_certificate/c\team_certificate: file:///var/lib/gremlin/pub_cert.pem' /etc/gremlin/config.yaml
sed -i '/#team_private_key/c\team_private_key: file:///var/lib/gremlin/priv_key.pem' /etc/gremlin/config.yaml
gremlin init -s autoconnect --tag instance_id=$INSTANCE_ID --tag owner=YOUR_NAME

This script adds the gremlin repository, installs the Gremlin agent and daemon, sets the configuration file with authentication details and instance tags, and finally starts the service to connect as a agent to Gremlin.

With everything ready, let’s run these templates.

BASH

terraform init
terraform apply

Again, indicate yes and Terraform will bring up an EC2 instance.A successful result will appear as below:

BASH

module.ec2.aws_instance.this: Creation complete after 22s
Apply complete! Resources: 1 added, 0 changed, 0 destroyed.

Now turn to the Agents page on Gremlin Control Panel.

You should see your newly brought up instance as an Online agent on Gremlin. Hooray!

Step 3: Run Your First Attack in your own Chaos Environment

Prepare a new Latency Gremlin Attack targeting the newly registered instance, but do not execute the attack just yet.

  • Log into the Gremlin web app.
  • Click Attacks in the left navigation bar, then click New Attack.
  • Select the Infrastructure tab, then select your EC2 instance. An easy way to find your instance is by entering its IP address or hostname in the search box.
  • Scroll down and click on the Choose a Gremlin section. Select the Network category, then select Latency.

Before starting the attack, SSH into the instance using your key file and start pinging www.google.com. You can do this by running the following commands on your local machine (make sure to swap in your own key file and IP address in place of <span class="code-class-custom">mykey.pem</span> and <span class="code-class-custom">34.214.21.96</span>.

BASH

ssh -i mykey.pem ec2-user@34.214.21.96

[ec2-user@ip-10-10-1-88 ~]$ ping www.google.com
PING www.google.com (173.194.202.99) 56(84) bytes of data.
64 bytes from pf-in-f99.1e100.net (173.194.202.99): icmp_seq=1 ttl=37 time=14.5 ms
64 bytes from pf-in-f99.1e100.net (173.194.202.99): icmp_seq=2 ttl=37 time=14.5 ms
64 bytes from pf-in-f99.1e100.net (173.194.202.99): icmp_seq=3 ttl=37 time=14.4 ms

Switch back to the browser where you have the Gremlin web app open and click Unleash Gremlin to execute the latency attack.  Once the attack enters the <span class="code-class-custom">Running</span> stage, switch back to the terminal where ping is running. You should see the round trip time increase by 100ms similar to the output below (note the change between lines 3 and 4):


64 bytes from pf-in-f99.1e100.net (173.194.202.99): icmp_seq=8 ttl=37 time=14.5 ms
64 bytes from pf-in-f99.1e100.net (173.194.202.99): icmp_seq=9 ttl=37 time=14.5 ms
64 bytes from pf-in-f99.1e100.net (173.194.202.99): icmp_seq=10 ttl=37 time=14.5 ms
64 bytes from pf-in-f99.1e100.net (173.194.202.99): icmp_seq=11 ttl=37 time=114 ms
64 bytes from pf-in-f99.1e100.net (173.194.202.99): icmp_seq=12 ttl=37 time=114 ms
64 bytes from pf-in-f99.1e100.net (173.194.202.99): icmp_seq=13 ttl=37 time=114 ms
64 bytes from pf-in-f99.1e100.net (173.194.202.99): icmp_seq=14 ttl=37 time=114 ms
64 bytes from pf-in-f99.1e100.net (173.194.202.99): icmp_seq=15 ttl=37 time=114 ms
64 bytes from pf-in-f99.1e100.net (173.194.202.99): icmp_seq=16 ttl=37 time=114 ms

Congratulations! In a very short amount of time, you have automated the creation of a completely new environment apart from the rest of your running resources, launched an instance that connects automatically to Gremlin, and ran your first attack in this environment.

If you are feeling adventurous, we highly recommend that you play around with Terraform. Create additional subnets in more availability zones. Create private subnets that talks through NAT gateway to the internet. Increase the instance count to launch more Gremlin instances. Also take a stab at running other attacks with Gremlin in this environment.

Step 4: Cleaning up.

Let’s first terminate the instance.

On your local machine:

BASH

cd ~/terraform/instance
terraform destroy

Similar to the creation of resources, Terraform will need you to confirm if you really want to destroy the resources.

BASH

Do you really want to destroy?
  Terraform will destroy all your managed infrastructure, as shown above.
  There is no undo. Only 'yes' will be accepted to confirm.

  Enter a value:

Enter yes, and Terraform will go ahead and destroy the resources.

BASH

Destroy complete! Resources: 1 destroyed.

Now go ahead and also destroy the VPC.

On your local machine:

BASH

cd ~/terraform/vpc
terraform destroy

Next time you want to spin up the environment again, simply use the templates you have used here, and you have your chaos environment within minutes.

Conclusion

By templatizing your chaos environment, you are able to quickly spin up an environment, run an attack to purposefully inject fault into the system, and return to zero footprint when you are done. Expanding on what you have achieved, if you also bring up your application within this environment, you're also able to evaluate and validate its resiliency against specific real-life operational scenarios. With the basics of running attacks down, you may want to think about running GameDays. If you need some help, here is How to Run a GameDay.

Appendix A - EC2 Permissions

You should have no issues if your user have the AdministratorAccess or AmazonEC2FullAccess policy attached. Otherwise, you will need permissions to the following API:


ec2:AssociateRouteTable
ec2:AttachInternetGateway
ec2:AuthorizeSecurityGroupEgress
ec2:AuthorizeSecurityGroupIngress
ec2:CreateInternetGateway
ec2:CreateRoute
ec2:CreateRouteTable
ec2:CreateSecurityGroup
ec2:CreateSubnet
ec2:CreateTags
ec2:CreateVpc
ec2:DeleteInternetGateway
ec2:DeleteRoute
ec2:DeleteRouteTable
ec2:DeleteSecurityGroup
ec2:DeleteSubnet
ec2:DeleteVpc
ec2:Describe*
ec2:DetachInternetGateway
ec2:DisassociateRouteTable
ec2:ModifySubnetAttribute
ec2:ModifyVpcAttribute
ec2:ReplaceRouteTableAssociation
ec2:RevokeSecurityGroupEgress
ec2:RevokeSecurityGroupIngress
ec2:RunInstances
ec2:TerminateInstances
